BW1010

Ampere Rating :


Battery Main Switch (1-2-Both-Off)
Interchangeable label stickers with removable ergonomic knob.
Available in surface mount and panel mount

BW1010
Part Number 65BW101044
Description 1000A (10 sec)
300A (5 min)
200A (1 hr)
Family Battery Switch
Category Battery Switch
Series B220
Voltage 48V
Rated Current 1000A (10 sec)
300A (5 min)
200A (1 hr)
Mounting Surface Mount or Panel Mount
Reset Type --
Dimension 69mm*69mm*73mmH
Termination M8

no information

no information

DIMENSION AND TRIP CURVE

69mm*69mm*73mmH
